OMBF is a product obtained by the self-etherification of HMF, which can be used as raw material to prepare polyamide and polyimide bio-based polymerization materials, and can also be used to synthesize heterocyclic ligands and hepatitis antiviral drug precursors.
| Product Name |
5, 5'(oxy- bis(methylene))bis- 2- furfural
|
| CAS No. |
7389-38-0
|
| Molecular Formula |
C12H10O5
|
| Molecular Weight |
234.20
|
| Melting Point | 113.5-115.5℃ |
| Boiling Point |
404.8±45.0℃
|
| Relative Density | 1.313g/cm³ at 25℃ |
| Stability |
Stable at room temperature, stored at 2-8℃ in a dry place, protected from light, and sealed
|
Chemical industry: Bio based polymer materials
Pharmaceutical industry : Hepatitis antiviral precursors
 |
| Purity 99.9% 50g |
Zhejiang Sugar Energy Technology Co., Ltd. (Sugar Energy Technology), established in 2017, is a national high-tech enterprise co-founded with participation from the Ningbo Institute of Materials Technology and Engineering, Chinese Academy of Sciences. As a professional China 5, 5' (oxy- bis (methylene) ) bis- 2- furfural (OBMF) Manufacturers and 5, 5' (oxy- bis (methylene) ) bis- 2- furfural (OBMF) Suppliers, focusing on the R&D, production and sales of bio-based furan new materials, the company leverages its advanced raw material production capabilities and downstream application innovation strengths to build a furan materials system of “1 high-end raw material + 5 platform molecules + N high-value products,” and aspires to become a leading bio-based materials enterprise driven by innovation and a strong sense of social responsibility.
Sugar Energy Technology’s flagship product, 5-hydroxymethylfurfural (HMF), is derived from a wide range of biomass feedstocks, including starch, cellulose, sucrose and agar. Featuring rare dual reactive functional groups and an aromatic structure, HMF not only helps improve the performance of other bio-based materials, but also opens up broader possibilities for the modification of conventional fossil-based products.
Guided by its founding mission, “Shaping the Beauty of Biology, Creating New Materials,” and its vision of “Building the world’s leading HMF monomer platform and making bio-based materials accessible to all,” Sugar Energy Technology continues to move forward toward a greener and more sustainable future.
R&D experience
Invention patent
Factory area
How Is HMF Created? The Chemistry in Plain Terms If you have ever watched honey darken during heating or smelled the toasty crust of fresh bread, you have already encountered 5-hydroxymethylfurfural ...
View More5-Hydroxymethylfurfural (HMF): Two Lives of a Remarkable Molecule HMF is already part of your morning routine. The brown note in your coffee, the amber depth of honey, the darkened edge of a carameli...
View MoreCarboxylic Acid FTIR: Three Bands, One Verdict A straightforward field guide for analysts who need a confident answer from an infrared spectrum in the first ten minutes. An off-white powder arrives o...
View MoreAs a 5 5 Oxy Bis Methylene Bis 2 Furfural manufacturer, we match product configuration to the application, operating limits, interfaces and acceptance criteria defined for each project.
Zhejiang Sugar Energy Technology Co., Ltd. manufactures 5, 5' (oxy- bis (methylene) ) bis- 2- furfural (OBMF) manufacturer as a high-purity derivative of 5-hydroxymethylfurfural (HMF). OBMF is produced via controlled self-etherification of HMF, yielding a difuranic dialdehyde that serves as a rigid, bio-based building block for polyamide, polyimide, and specialty polymer systems. We supply OBMF to R&D laboratories, pilot-scale developers, and industrial chemical manufacturers targeting sustainable alternatives to fossil-derived diamines and dialdehydes.
Our OBMF is part of the furan materials system built around HMF as the core raw material. With a 2,000-ton/year HMF production capacity and continuous process technology, we ensure consistent monomer quality for downstream derivatization. The product is available in research quantities (50 g) and can be scaled for custom orders.
| Property | Value |
|---|---|
| Product Name | 5, 5' (oxy- bis (methylene)) bis- 2- furfural (OBMF) |
| CAS Number | 7389-38-0 |
| Molecular Formula | C₁₂H₁₀O₅ |
| Molecular Weight | 234.20 g/mol |
| Melting Point | 113.5 – 115.5 °C |
| Boiling Point | 404.8 ± 45.0 °C (predicted) |
| Relative Density | 1.313 g/cm³ at 25 °C |
| Stability | Stable at room temperature; store at 2–8 °C in dry, light-protected, sealed container |
| Purity (HPLC) | ≥ 99.9% |
OBMF contains two aldehyde functional groups connected by an ether-linked bis-furan backbone. This structure makes it suitable for:
We supply OBMF in the following standard configurations:
| Package | Typical Use |
|---|---|
| 50 g sealed bottle | R&D screening, small-scale synthesis |
| 500 g / 1 kg | Process development, pilot trials |
| Custom bulk (drums, IBC) | Industrial-scale production campaigns |
All packages are nitrogen-blanketed and shipped under temperature-controlled conditions to maintain stability during transit. We recommend storage at 2–8 °C upon receipt.
Each OBMF batch is tested in our in-house laboratory. Our quality program includes:
A Certificate of Analysis (CoA) accompanies every shipment. Additional characterization (TGA, DSC, elemental analysis) can be arranged on request.
OBMF is a stable solid under recommended storage conditions. Operators should follow standard chemical hygiene practices:
Shelf life is 12 months from the date of manufacture when stored at 2–8 °C in the original sealed container. We do not recommend freezing; condensation upon thawing may introduce moisture.
OBMF is designed for direct use in polymerization or organic synthesis without additional purification. For polyamide synthesis, typical reaction conditions involve solution or melt polycondensation with diamines under inert atmosphere. We can provide recommended reaction parameters and compatibility data upon request.
Our technical team supports scale-up from gram to multi-kilogram quantities. If you are developing a continuous process or require custom particle size distribution, contact us with your target specifications.
To configure the right supply package and provide accurate pricing, we need the following project details:
We respond to technical inquiries within 12 working hours. For urgent projects, call +86-13616880147 (Zoe) or email [email protected].
OBMF is one of several high-value derivatives we produce from HMF. Explore our complete furan materials range:
Q: What is the typical lead time for OBMF orders?
A: For standard 50 g to 1 kg packages, we ship within 5–7 working days after order confirmation. Bulk quantities (≥ 10 kg) require 2–3 weeks depending on production schedule and custom packaging.
Q: Can you provide a sample for evaluation?
A: Yes, we offer a 50 g sample for qualified R&D projects. Please submit a brief description of your application, and we will arrange shipment with a proforma invoice.
Q: Is OBMF REACH registered or TSCA listed?
A: OBMF is not yet REACH registered. We can provide regulatory status documentation and support your registration if needed. For TSCA, please confirm your jurisdiction; we will supply the relevant compliance data.
Q: What is the solubility of OBMF?
A: OBMF is soluble in common organic solvents such as ethanol, acetone, ethyl acetate, and THF. It has limited solubility in water. We can provide solubility screening data on request.
Q: Do you offer custom purity grades or particle sizes?
A: We can adjust purity specifications and milling to a target particle size for dedicated projects. Minimum order quantities apply for custom grades. Contact our technical sales team to discuss feasibility.
Q: How do you ensure batch-to-batch consistency?
A: Our HMF continuous production line (2,000 tons/year) provides a consistent starting material. OBMF is produced under controlled self-etherification conditions with in-process monitoring. Each batch is tested against release specifications before shipment.
